Genesis Pro Series Shears are hydraulic attachments, which, through use of an excavator's hydraulic system, can effectively process ferrous and non-ferrous metals as well as a host of other materials. Genesis Pro Series Shears are available in twelve models and sizes to fit excavators from 30,000 to 230,000 lbs.; models featuring full 360° rotation are available. All Genesis Pro Series Shears offer excellent cutting forces and cycle times made possible through use of a proprietary GenFlow hydraulic regeneration system and large-bore heavy duty cylinder. Every Genesis Pro Shear is covered by an 18-month, 2,500 hour (whichever occurs first) warranty on the shear superstructure and a 12-month, 1,500 hour warranty on all hydraulic components. |
| Model | Shear Force | Weight | Jaw Opening | Jaw Depth | Reach | Excavator Wgt Boom Mount | Excavator Wgt Stick Mount |
|---|---|---|---|---|---|---|---|
| GSM 300 | 695 tons | 6,500 lbs | 23" | 24" | 6'-5" | 30,000 lbs | 45,000 lbs |
| GMS 300R | 695 tons | 7,400 lbs | 23" | 24" | 8'-0" | 37,000 lbs | 67,000 lbs |
| GMS 400 | 910 tons | 8,200 lbs | 28" | 29" | 7'-6" | 37,000 lbs | 67,000 lbs |
| GMS 400R | 910 tons | 10,200 lbs | 28" | 29" | 11'-0" | 46,000 lbs | 85,000 lbs |
| GMS 500 | 1,105 tons | 10,200 lbs | 32" | 33" | 8'-6" | 50,000 lbs | 90,000 lbs |
| GMS 500R | 1,105 tons | 11,900 lbs | 32" | 33" | 12'-0" | 65,000 lbs | 110,000 lbs |
| GMS 700 | 1,270 tons | 12,000 lbs | 35" | 37" | 9'-0" | 65,000 lbs | 110,000 lbs |
| GMS 700R | 1,270 tons | 14,800 lbs | 35" | 37" | 13'-0" | 88,000 lbs | 150,000 lbs |
| GMS 1000 | 1,500 tons | 14,300 lbs | 38" | 40" | 10'-6" | 88,000 lbs | 150,000 lbs |
| GMS 1000R | 1,500 tons | 16,800 lbs | 38" | 40" | 13'-6" | 98,000 lbs | 170,000 lbs |
| GMS 1400 | 2,065 tons | 19,600 lbs | 42" | 42" | 11'-0" | 130,000 lbs | 185,000 lbs |
| GMS 1400R | 2,065 tons | 24,000 lbs | 42" | 42" | 15'-0" | 170,000 lbs | 250,000 lbs |
| *Extended reach brackets are available on all non-rotating shears. All Genesis Pro Series "R" shears feature continuous 360° rotation. Genesis Pro Series shears are covered by an 18-month 2,500-hour (whichever occurs first) warranty on the shear superstructure and a 12-month 1,500-hour warranty on all hydraulic components. |
 |
| Ransome Equipment Sales, LLC |
| 5118 Church Road, Mt. Laurel, NJ 08054 |
| Toll Free Phone: 888-726-7863 Phone: 856-778-4070 Fax: 856-778-4249 |
| E-mail: sales@ransome-equip.com |
| Revised: 12/17/2005 |
